Looks like he had black, white, and mostly green wires. ???? Nicely routed.
-
Don't see the incoming mains but I guess it's there somewhere, yah?
-
Just a thought... When you get the pump running on FROG control, try taking the L,N output to the pump from your "smart box" to the L,N in the FROG control (replacing the mains incomer). Forget about the capacitor in the smart box.
-
I took a photo of my FROG control where the pump wires come in. Looks like L is brown, N blue, and can't see capacitor wire but it would be whatever is left (maybe red). Hook it up like that and your pump will work. Don't worry about the capacitor. FROG will have it hooked up the way they want it.
-
Did you change the wiring in the control box? All you should need to do is connect the incoming L,N,E to the connectors for that and connect the pump wires to the connector block for that. The brown wire is for the capacitor.
-
Pretty sure blue is N and black is L in the control box (NOT as labeled above). My recall is that the pump wires are black for L, grey for neutral, brown for capacitor and yellow-green for earth.
-
These pumps are resilient so I don't think you blew it up. How did you measure 220V across the windings? Make sure you have 220V between L and N on the incomer.
-
Make sure you didn't trip anything. ????
-
The 4 wires to the pump are L,N,E,Capacitor. I wonder why it only shows the capacitor connected?
-
I've found something handy to have for a lot of things is the hot glue gun used by hobbyists.
-
I don't know, but that looks horizontal to me. ????
-
The only stick sold locally is what they label "RB-26". Does the job but inconsistent in burning. Easily flares out and punches a hole and then can be "normal" for a while.
