Bandersnatch

7 minutes ago, johng said:

Ok lots of  insulation   but how does the room get down to 26 degrees in the first place ?

You could also ask how my bedroom is mid 20s°C when it is 14°C outside in the winter.

Try this link https://physics.stackexchange.com/questions/83006/why-basements-stay-cold-even-during-summer

33 minutes ago, johng said:

How does the inside temp get down to  26 degrees whilst its 45 degrees outside  without using aircon ?

This only happens in the main bedroom which is the central core of the building. It is like being in an underground cave. You really need to read my whole blog  https://ecohousethailand.com/ to fully understand the degree to which insulation has been designed into the building. The walls are a foot thick, with 3 inches of foam under the floor, in the ceiling and in the walls. There is an aircon unit in the bedroom, but it is the smallest BTU I could find 8,500 BTU

1 hour ago, trucking said:

Another good idea is to try to get your whole house in the shade by surrounding with tall trees. This helps a lot and can gain you a few degrees. Sadly , only managed this on a small section of ours as space is a bit tight.

I have solar panels on all four cardinal directions to catch the sun as it moves.

I agree shading helps to cool the house, but I am happy to get this bill from PEA every month

1 minute ago, trucking said:

Impressive. Well thought out but sadly , beyond a lot of peoples budgets.



Must be pretty cool even with the air con off.

This indoor/outdoor temperature reading is taken with the air con off:

2 minutes ago, trucking said:



So your walls are about 1 ft thick ?   I guess you have double glazing too ?

I have three zones in the house build:

1) Shaded outside under roof but no walls

2) Buffer zone with no air-con: kitchen, bathrooms, porch, mechanical room - which have normal windows

3) Inner zone with aircon and glass block windows. Ventilation is provided by an energy recovery ventilator

1 minute ago, scubascuba3 said:

Very smart, using wind seems the best way to do it

I combine natural ventilation with lots of insulation: - My walls are made of sandwich  of 2 layers of  Aerated Concrete Blocks, double sided foil insulation, air gap, 3 inches of foam insulation, second air gap, then the second wall. Wrap around porch roof to keep sun off the walls and windows. Small narrow windows positioned high up under the porch roof. All walls painted bright white.


1 hour ago, Skylight said:



Yeah aesthetically it would be a little bit out there but I am sure you got a cool house.  I'll have to think about it for a long while.



How is the design treating you.  The house is pretty cool all day?

It is far cooler on the third floor than at ground level, this is partly due to the fact that wind speeds are higher with increased height, but the speed of the wind is further increased by the building design. The wind is funnelled by the sloping roof and partial side walls, this  phenomenon is called The Venturi Effect

When no aircon is being used, the doors in the stairwells are opened to aid with natural cooling, using a principal called Stack Effect Ventilation: having an opening at the top of the building, draws heat up and out like a chimney. The effect is magnified by the higher wind speed on the third floor caused by the The Venturi Effect which creates a partial vacuum in the stairwell. It is like adding an extractor fan to the chimney.

1 minute ago, scubascuba3 said:

the main building just has a flat roof?

I designed my house to have a roof designed to a vent and cool via natural airflow with no heat build up. You end up with an unconventional design, which may not appeal aesthetically to all tastes, but it does prevent heat from being transferred down into the house.

1 hour ago, Rancid said:

Very interesting movie. Progressives hated it as it puts lie to the many claims of renewable green energy, as it turns out it isn't. Sadly climate change is not about cleaning up the planet, but simply another profit zone for the usual gang of environmental rapists. Unfortunately the excellent questions it raised were immediately swept under the carpet by the compliant & owned media.

Much of the video in this movie dates from 2005, when green energy was nothing to shout about.

38 minutes ago, Grumpy John said:

What is your home solar system? How many kilowatts? How much use will the electric car get? Just making a blanket statement and not providing some statistics means F all.  ....

I am sorry you didn't understand my reply, but you needed to read it conjunction with the post I was replying to which was that electric cars will result in More Dirty Power stations. All you needed to know what that my solar installation is designed to charge the house and an EV, so no more Dirty Power stations in my case, which is what I said. My system is 11.2kW of PV and 38.4kWH of storage, my PEA bill each month is 39 Baht. I don't commute or go on long road trips

I do however, object to your language and have reported your post.

44 minutes ago, JesseBronson said:

I am looking at a new electric car, but not until they ditch the import duties !



Now Tesla Shanghai is in production, we just have to wait until they start exporting to Thailand. Import tax on Chinese cars is 0% compared to 80% from Europe, 40% from Korea and 20% from Japan.

On 9/5/2020 at 1:44 PM, scammed said:

i dont mind electric cars, but i do mind subsidies

that pervert the market

I agree with you

https://www.forbes.com/sites/jamesellsmoor/2019/06/15/united-states-spend-ten-times-more-on-fossil-fuel-subsidies-than-education/#3c9eb2974473

On 9/4/2020 at 6:10 PM, digger70 said:

Big Scam Biggest Rip off yet.

How are the Power stations going to keep up with all the power using vehicles?

Make More Dirty electric power? More Dirty Power stations

Who's going to benefit ? Power Station Moguls. Car Factories

Price of Electricity will go Sky high.

My home solar system is designed to charge an electric car. For those without solar, then smart grids, time of use electric pricing and bi-directional EV charging will soon mitigate the need for peaker power plants.

On 9/4/2020 at 2:27 PM, scammed said:

no for christ sake cum off it



The film includes a great deal of outdated, inaccurate and misleading information.

Watch this review of the film

Planet of the Humans : Let's just have a think

On 8/29/2020 at 3:34 PM, natway09 said:

Next is the battery disposal

MGZS EV's 44.5kWh Lithium Ion Battery has an 8 year warranty in Thailand against suffering a capacity drop below 70% of the original capacity.
So after 8 years the car will be able to still drive 233.8km under the NEDC driving mode.

Alternatively it could be used as backup storage for a solar system as it still has the equivalent capacity of 2.3 Tesla Power-walls.

On 9/3/2020 at 12:24 PM, richard_smith237 said:

A rather vague comment that....   How quickly ?



Other threads on this subject imply about 10 years to recover costs, by which time the cells themselves may need replacement incurring further costs.



Cost of purchase, installation and available ‘roof’ space are key factors.



I’m not convinced solar panels in Thailand are an economically viable solution. Additionally, the MEA do no offer ‘buy back’ power options and would actually fine someone who ’trickle power back’ to turn back the meter in periods of low use.

Payback depends on the size of your system. A very large system designed to be completely off-grid and charge an electric car like my system will take 10 years to payback (including installation), but smaller systems covering say 60% of the bill, will payback much quicker. Remember a 10 year payback is a 10% return, try getting that in the bank.

My solar panels come with a 20 year guarantee

"Photovoltaic systems typically last 25 to 40 years"

https://en.wikipedia.org/wiki/Solar_power

MEA and PEA both offer a buy back scheme called the solar rooftop scheme for residential PV

Try Pong Thai Village หมู่บ้านพงษ์ไทย Salak Dai, Mueang Surin - always have places to rent 3 bed 2 bath pool and a gym about 4k / month

https://goo.gl/maps/vn7aLUhV74peEzDF6

31 minutes ago, pineapple01 said:

It was usefull in power cuts. Thats about all.

Having solar also protects you from rising Electric bills.


On 5/19/2020 at 5:47 PM, moe666 said:

It always boils down to how long is the pay  out. 10 years, 20 years 25years will you still be alive. Same for elect cars. Solar homes also a waste, to hot in the summer too cold in the winter, just too hot in thailand.

If you are short of money and need a very quick payback. I would suggest aiming to cover 60% of your electric bill with solar and not installing batteries. This is the low hanging fruit and would have produced a payback of about 5 years in my case. I chose to go off-grid with PEA as a backup, which meant I needed batteries and an excess of solar to cover cloudy days. My over-the-top system has a payback of 10 years. I am not sure where you got 25 years from. Is that based on an install in Thailand or New Mexico?

"Solar homes also a waste, to hot in the summer too cold in the winter, just too hot in thailand."

I have no problem running aircon on my solar system system. But if money is tight I would suggest spending the money on insulation first and solar later if you can afford it.

My solar house is lovely and cool, but I did insulate.

Being reliant on income from abroad is a risk with currency movements.  My approach has been to reduce my future costs as far as possible. 1st put 800k/400k away and don't touch it. That way your visa is safe.

I don't pay rent; condo fees; water or waste water bills; rubbish collection bills; electric bills. I don't have any debts. I don't have any expensive addictions. I am growing some of my food. So if push comes to shove, I could survive on very little. My spreadsheet shows my income sources linked to the current exchange rate. I should be ok if the pound goes down to less than 10 Baht.


It is also good to have some income in Thai Baht and an emergency fund if possible.

19 minutes ago, Crossy said:

I did think Fort Knox, is the basement full of bullion? Interesting concept, it doesn't float my boat but we all have different tastes.



Our home is discussed at length in another thread, but here's a taster, solar is on the car-port right of frame.

Hi Crossy, I know your build. It is without a doubt a very beautiful house.

I set out in my design criteria that I wanted to build an off grid house - designed with solar in mind and super insulated. Compromises have to be made and for me that was the aesthetics.

Being a bit of a prepper, I can confirm that Gold has done well recently.
