33 minutes ago, Justgrazing said:

Hemispherical comb' chamber yep' but take a look at how wide the angle of the valve seats are from the vertical .. That wide will promote to a degree better airflow into a hemi' chamber but will result in a wide cyl head casting to accommodate the valve gear ..



Wot?

A bit like my Triumph then, based on the iron heads of the 1937 Speed Twin, and later the first 50's 650 alloy heads.....

You wanna see hemi heads on a bike?

Check out late BMW R series air heads from the 70's and post war Harleys - very very poor combustion unless running stupid octane and stupid compression ratios.

Hence why i have pinking/detonation probs on the T140 in extreme heat here - solution don't ride it when temps are hitting or approaching 40C....






  • Like 1
Posted (edited)
1 hour ago, thaiguzzi said:

A bit like my Triumph then, based on the iron heads of the 1937 Speed Twin, and later the first 50's 650 alloy heads.....

You wanna see hemi heads on a bike?

Check out late BMW R series air heads from the 70's and post war Harleys -

Yea sure I'm not saying the Noug' was pioneering but it was doing it with DOHC's which is why that head on the 250 is so wide .. Wide angle valves without a widehead usually requires rockers , rocker-shafts and gubbins if you stay with pushrods which adds friction , weight and ultimately less than accurate valve opening and closing .. if you go single OHC it usually has to be centrally located between the valves and then operate rockers ( a lot of 80's mundane Japanese 4 cyl cars used this setup to keep the head fairly narrow ) but again needs rocker's and shaft's .. Purest and most accurate valve opening and closing ( desmodromic aside ) in OHC is the lobe operating directly onto the top of the valve via a bucket or shim holder as it does away with the need for any other components which increases accuracy of operation but if the valves are wide angle then a wide head is required .. This is one of the reasons the Jaguar V12 was not fitted with DOHC heads modelled on the XK 6 banger hemi' design .. with the cams operating directly on the top of the valves the hemi design of the heads on a 60 degree angle wide block was too wide to allow induction from the inner faces of the heads which is why the prototype engine in the pic has the abomination of the inlet manifold entering thru the other side of inlet cams .. That the induction was compromised by that idea is an understatement as heat soak rises directly to the carbs and inlet manifold's .. The decision then was taken to keep it a single chain driven OHC operating directly onto the top of the valve which kept it all very neat and narrow but ruled out the use of a hemi' combustion chamber which is why the early production engine ( upto 1981 ) was a flat Heron head with the chamber in the top of the piston ..


Edited by Justgrazing
Sp
  • Like 2
Posted (edited)

Couple of other takes on wide valve angles ..

Be-eM HP2 boxer head with DOHC on wide'ish angle valves using rockers on the outside of the cams ..

Rudge Python 350 with wide radial angle valves but as motion comes from pushrods it has to have a number of rockers to transfer that motion .. Primary rocker that takes the motion from the pushrod also has to operate the secondary rocker ( yellow ) to open the other valve .. this all allows loss of motion , increased friction and given the angles they are working at wear on the rocker tips and top of the valve stem .. But this is a 1930's engine and the use of OHC's to drive wide angle radial valves was still not popular among many engine makers ..

And engine in bike .. What a neat looking machine ..






Edited by Justgrazing
Sp
  • Like 2
Posted (edited)
3 hours ago, ballpoint said:

doubt if there was, or will be, any other country to have such a sheer magnitude of mechanical genius as England (for, as thaiguzzi pointed out some time ago, although British is the usual term, 99% of them were English) in the first half of the 20th century.  It seems you could walk into any garage at random and find someone building a car or motorcycle or aircraft engine.

Germany are not bad either when you look back at that era though a lot of it like the first operational jet powered planes with the ME262 fighter and Arado 234 bomber ( never used in anger as it arrived WW2 too late .. this plane is believed to be the last operational Luftwaffe aircraft to fly over Blighty early in '45 on a reconnaissance flight ) along with projects like the V rockets were all for the wrong reasons ..

But hey we won and after we got over the hangover and surveying the new order there was only one thing for it .. Jets .. and lots of 'em .. The 50's Brit' aero industry was arguably the best in the world with loads of manufacturers .. Even the A-mericans were reg' visitors to airshows in Britain to watch kit being put thru' it paces with a view to purchase ( and plagiarising ) .. Even the Russian top brass would be cordially invited to Farnborough in stage managed visits to watch our latest military planes doing barrel rolls and full throttle ascents and dives ..

And one such bit of kit that could not have failed to get their attention was the 50's English Electric Lighting .. Primary task was to intercept Soviet bombers in the event of Armageddon arriving for real .. And intercept it could .. only British made plane of the era capable of Mach 2 and described by many pilots as like getting strapped into a rocket and watching the world go backwards .. Its speed though was matched by its thirst for Avgas limiting early versions operational range but the Russian's had no answer to it .. remained with some squadrons until the mid 80's though not as No1 front line ..

If bikes are planes then for its consumption alone the Lightning is a Kawa H2 with spannies and no filter ..





Edited by Justgrazing
Sp
  • Like 2
Posted
29 minutes ago, Justgrazing said:

Its speed though was matched by its thirst for Avgas limiting early versions operational

Jets don't use Avgas; only internal combustion engines do.

Posted

Back on the ground, I'd love to get one of these for the farm, but not seen any in Thailand.  A Crayford Argo Cat with removable rubber caterpillar tracks.


  • Like 2
Posted
6 minutes ago, VocalNeal said:

1950 Rover Jet-1 saw it as a lad in The Science Museum

Superb V N .. the turbine Rover .. Glad you reminded us of that .. Good call man ..

Posted
9 hours ago, ballpoint said:

Looking back at all those long lost manufacturers and their magnificent machines

From you're list above BP ..

The last Arab Villiers ever made so they say ..

And starting with a B but long since lost also .. a couple of Blackbournes .. Gorgeous paint on both of 'em ..







  • Like 1
Posted
49 minutes ago, Justgrazing said:

... One more bang of the nations drum ..

The Vulcan bomber .. Angel of Death if it was ever to be used in proper anger ..




I worked with a former RAF pilot who used to fly them.

  • Like 2
