Ok here is the diagrams for the filter setup. photo won't show all. I apologize for the errors. I am just learning Sketchup and I haven't figured out how to do pipes properly.



One part of the filter I consider very important is the 4 meters of 3 inch pipe that runs from the center bottom of the fish tank and tees up into filter 1.

This is a long level passage where lots of solids will drop out before they even reach the filters. I have a big valve further down which when I crack it open sends anything in that pipe on a 10 meter drop with all of the waste water. An advantage of living on a hill.

Edited by canuckamuck
